HEATCORE
4-In-1 PTC Retrofit Bathroom Heater
Finish Colour
White
Black
Heatcore replaces traditional infrared systems with advanced heating, ventilation and lighting technology, delivering improved comfort and efficiency.
Features:
- Digital Wall Controller:
Simple one-touch operation with intuitive control of every function. - Tri-Colour Switchable Light:
Select your preferred colour temperature. - Advanced Safety Feature:
Automatic two-hour shut-off for added safety and peace of mind. - Retrofit Compatible Covering Most Existing 2&4 Heat Infrared Models
- Available In White and Black Colour Options
Design Registration Number: 202614158
Specifications
Wattage
2250W
Finish Colour
White
Black
Colour Temperature
3000K - 4000K - 5000K (Switchable)
Cutout Diameter
330x350mm
Light Wattage
12W
Heat Type
PTC Heating Element
Air Extraction
300m3/h
Lumen Output
850lm/950lm/900lm
Variants
| Image | Variant ID | Item No. | Wattage | Finish Colour | Colour Temperature | Cutout Diameter | Light Wattage | Heat Type | Air Extraction | Downloads |
|---|---|---|---|---|---|---|---|---|---|---|
|
|
56024 | BH-HEATCORE | 2250W | White | 3000K - 4000K - 5000K (Switchable) | 330x350mm | 12W | PTC Heating Element | 300m3/h |
|
|
|
56025 | BH-HEATCORE | 2250W | Black | 3000K - 4000K - 5000K (Switchable) | 330x350mm | 12W | PTC Heating Element | 300m3/h |
|
Variant ID
56024
Item No.
BH-HEATCORE
Wattage
2250W
Finish Colour
White
Colour Temperature
3000K - 4000K - 5000K (Switchable)
Cutout Diameter
330x350mm
Light Wattage
12W
Heat Type
PTC Heating Element
Air Extraction
300m3/h
Variant ID
56025
Item No.
BH-HEATCORE
Wattage
2250W
Finish Colour
Black
Colour Temperature
3000K - 4000K - 5000K (Switchable)
Cutout Diameter
330x350mm
Light Wattage
12W
Heat Type
PTC Heating Element
Air Extraction
300m3/h
