PLEO-7.2-S
Side View Neo Flex LED Strip
Colour Temperature
3000K
4000K
5000K
The PLEO-7.2 series is available in both front-facing and side-view formats, making it ideal for horizontal and vertical illumination applications.
Features:
- Flexible low-voltage Neon Flex in a durable polyurethane enclosure
- Supplied with mounting clips for quick and easy installation
- Available in three colour temperatures
- High CRI90 for exceptional colour rendering
- Extended continuous runs up to 20m (single-feed) or 40m (dual-feed)
- Weatherproof design for indoor and outdoor applications
- Smooth, seamless neon-style illumination
- Ideal for coves, walls, windows, signage, and architectural features
- Suitable for residential, commercial, and creative lighting projects
- Reliable, low-maintenance lighting solution for long-run installations
Specifications
Roll Length
Sold Per Metre
20 Metre Roll
Wattage
7.2W
Input Voltage
24V DC
Colour Temperature
3000K
4000K
5000K
IP Rating
IP67
Dimming
Yes
Operating temperature
-15ºC to 85ºC
Requires
Requires a driver
Variants
| Image | Variant ID | Item No. | Roll Length | Wattage | Input Voltage | Colour Temperature | IP Rating | Dimming | Operating temperature | Downloads |
|---|---|---|---|---|---|---|---|---|---|---|
|
|
20381 | PLEO-7.2-S | Sold Per Metre | 7.2W | 24V DC | 3000K | IP67 | Yes | -15ºC to 85ºC |
|
|
|
20382 | PLEO-7.2-S | Sold Per Metre | 7.2W | 24V DC | 4000K | IP67 | Yes | -15ºC to 85ºC |
|
|
|
20383 | PLEO-7.2-S | Sold Per Metre | 7.2W | 24V DC | 5000K | IP67 | Yes | -15ºC to 85ºC |
|
|
|
20404 | PLEO-7.2-S-20M | 20 Metre Roll | 7.2W | 24V DC | 3000K | IP67 | Yes | -15ºC to 85ºC |
|
|
|
20405 | PLEO-7.2-S-20M | 20 Metre Roll | 7.2W | 24V DC | 4000K | IP67 | Yes | -15ºC to 85ºC |
|
|
|
20406 | PLEO-7.2-S-20M | 20 Metre Roll | 7.2W | 24V DC | 5000K | IP67 | Yes | -15ºC to 85ºC |
|
Variant ID
20381
Item No.
PLEO-7.2-S
Roll Length
Sold Per Metre
Wattage
7.2W
Input Voltage
24V DC
Colour Temperature
3000K
IP Rating
IP67
Dimming
Yes
Operating temperature
-15ºC to 85ºC
Variant ID
20382
Item No.
PLEO-7.2-S
Roll Length
Sold Per Metre
Wattage
7.2W
Input Voltage
24V DC
Colour Temperature
4000K
IP Rating
IP67
Dimming
Yes
Operating temperature
-15ºC to 85ºC
Variant ID
20383
Item No.
PLEO-7.2-S
Roll Length
Sold Per Metre
Wattage
7.2W
Input Voltage
24V DC
Colour Temperature
5000K
IP Rating
IP67
Dimming
Yes
Operating temperature
-15ºC to 85ºC
Variant ID
20404
Item No.
PLEO-7.2-S-20M
Roll Length
20 Metre Roll
Wattage
7.2W
Input Voltage
24V DC
Colour Temperature
3000K
IP Rating
IP67
Dimming
Yes
Operating temperature
-15ºC to 85ºC
Variant ID
20405
Item No.
PLEO-7.2-S-20M
Roll Length
20 Metre Roll
Wattage
7.2W
Input Voltage
24V DC
Colour Temperature
4000K
IP Rating
IP67
Dimming
Yes
Operating temperature
-15ºC to 85ºC
Variant ID
20406
Item No.
PLEO-7.2-S-20M
Roll Length
20 Metre Roll
Wattage
7.2W
Input Voltage
24V DC
Colour Temperature
5000K
IP Rating
IP67
Dimming
Yes
Operating temperature
-15ºC to 85ºC
