PLEX-COB-5
COB True Dotless LED Strip
Colour Temperature
2700K
3000K
4000K
5000K
The PLEX-COB Series combines advanced COB LED technology with a seamless, true dotless appearance for premium linear lighting applications.
Features:
- Advanced COB technology with 640 LEDs/m for a seamless, dotless appearance
- 24V DC operation for reduced heat and longer run lengths
- Available in IP54 Indoor and IP67 Waterproof versions
- High CRI90 for superior colour rendering
- Wattage options: 5W, 10W, 15W, and 20W per metre
- Colour temperatures: 2700K, 3000K, 4000K, and 5000K
- Weldless joint design for improved reliability and continuity
- Smooth, uniform linear lighting with a clean architectural finish
- Compatible with fast-fix, L-joint, and strip connectors for flexible installations
- Ideal for kitchens, bathrooms, laundries, bars, restaurants, and feature lighting applications
Specifications
Roll Length
Sold Per Metre
20 Metre Roll
50 Metre Roll
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
400lm
450lm
500lm
Colour Temperature
2700K
3000K
4000K
5000K
CRI
≥90
IP Rating
IP54
Dimming
Yes
Variants
| Image | Variant ID | Item No. | Roll Length | Wattage | Input Voltage | Lumens Per Metre | Colour Temperature | CRI | IP Rating | Downloads |
|---|---|---|---|---|---|---|---|---|---|---|
|
|
23962 | PLEX-COB-5 | Sold Per Metre | 5W | 24V DC | 400lm | 2700K | ≥90 | IP54 |
|
|
|
24000 | PLEX-COB-5 | Sold Per Metre | 5W | 24V DC | 450lm | 3000K | ≥90 | IP54 |
|
|
|
24001 | PLEX-COB-5 | Sold Per Metre | 5W | 24V DC | 500lm | 4000K | ≥90 | IP54 |
|
|
|
24002 | PLEX-COB-5 | Sold Per Metre | 5W | 24V DC | 500lm | 5000K | ≥90 | IP54 |
|
|
|
24014 | PLEX-COB-5-20M | 20 Metre Roll | 5W | 24V DC | 450lm | 3000K | ≥90 | IP54 |
|
|
|
24015 | PLEX-COB-5-20M | 20 Metre Roll | 5W | 24V DC | 500lm | 4000K | ≥90 | IP54 |
|
|
|
24016 | PLEX-COB-5-20M | 20 Metre Roll | 5W | 24V DC | 500lm | 5000K | ≥90 | IP54 |
|
|
|
23969 | PLEX-COB-5-50M | 50 Metre Roll | 5W | 24V DC | 400lm | 2700K | ≥90 | IP54 |
|
|
|
24028 | PLEX-COB-5-50M | 50 Metre Roll | 5W | 24V DC | 450lm | 3000K | ≥90 | IP54 |
|
|
|
24029 | PLEX-COB-5-50M | 50 Metre Roll | 5W | 24V DC | 500lm | 4000K | ≥90 | IP54 |
|
|
|
24030 | PLEX-COB-5-50M | 50 Metre Roll | 5W | 24V DC | 500lm | 5000K | ≥90 | IP54 |
|
Variant ID
23962
Item No.
PLEX-COB-5
Roll Length
Sold Per Metre
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
400lm
Colour Temperature
2700K
CRI
≥90
IP Rating
IP54
Variant ID
24000
Item No.
PLEX-COB-5
Roll Length
Sold Per Metre
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
450lm
Colour Temperature
3000K
CRI
≥90
IP Rating
IP54
Variant ID
24001
Item No.
PLEX-COB-5
Roll Length
Sold Per Metre
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
500lm
Colour Temperature
4000K
CRI
≥90
IP Rating
IP54
Variant ID
24002
Item No.
PLEX-COB-5
Roll Length
Sold Per Metre
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
500lm
Colour Temperature
5000K
CRI
≥90
IP Rating
IP54
Variant ID
24014
Item No.
PLEX-COB-5-20M
Roll Length
20 Metre Roll
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
450lm
Colour Temperature
3000K
CRI
≥90
IP Rating
IP54
Variant ID
24015
Item No.
PLEX-COB-5-20M
Roll Length
20 Metre Roll
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
500lm
Colour Temperature
4000K
CRI
≥90
IP Rating
IP54
Variant ID
24016
Item No.
PLEX-COB-5-20M
Roll Length
20 Metre Roll
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
500lm
Colour Temperature
5000K
CRI
≥90
IP Rating
IP54
Variant ID
23969
Item No.
PLEX-COB-5-50M
Roll Length
50 Metre Roll
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
400lm
Colour Temperature
2700K
CRI
≥90
IP Rating
IP54
Variant ID
24028
Item No.
PLEX-COB-5-50M
Roll Length
50 Metre Roll
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
450lm
Colour Temperature
3000K
CRI
≥90
IP Rating
IP54
Variant ID
24029
Item No.
PLEX-COB-5-50M
Roll Length
50 Metre Roll
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
500lm
Colour Temperature
4000K
CRI
≥90
IP Rating
IP54
Variant ID
24030
Item No.
PLEX-COB-5-50M
Roll Length
50 Metre Roll
Wattage
5W
Input Voltage
24V DC
Lumens Per Metre
500lm
Colour Temperature
5000K
CRI
≥90
IP Rating
IP54
