PLEX-MICRO
Micro Width LED Strip
Colour Temperature
2700K
3000K
4000K
5000K
The PLEX-MICRO series is a specially designed micro-width LED Strip that offers applications where small spaces require smaller than 10mm widths.
Features:
- Advanced COB technology with 480 LEDs/m for a true dotless appearance
- Compact 8W/m design with bright, uniform light output
- 24V DC operation for reduced heat and longer run lengths
- Available in IP54 Indoor options suitable for wet areas
- High CRI90 for excellent colour rendering
- Available in 2700K, 3000K, 4000K & 5000K colour temperatures
- Weldless joint design for improved reliability and continuity
- Smooth, seamless linear illumination with a clean architectural finish
- Compatible with fast-fix, L-joint, and strip connectors for flexible installations
- Ideal for kitchens, bathrooms, laundries, hospitality, retail, and feature lighting applications
Specifications
Wattage
8W
Input Voltage
24V DC
Colour Temperature
2700K
3000K
4000K
5000K
Lumens per metre
540lm/640lm/680lm/720lm
CRI
≥90
IP Rating
IP54
Dimming
Yes
Roll Length
1 Metre
Variants
| Image | Variant ID | Item No. | Wattage | Input Voltage | Colour Temperature | Lumens per metre | CRI | IP Rating | Dimming | Downloads |
|---|---|---|---|---|---|---|---|---|---|---|
|
|
24118 | PLEX-MICRO-8W | 8W | 24V DC | 2700K | 540lm/640lm/680lm/720lm | ≥90 | IP54 | Yes |
|
|
|
24162 | PLEX-MICRO-8W | 8W | 24V DC | 3000K | 540lm/640lm/680lm/720lm | ≥90 | IP54 | Yes |
|
|
|
24163 | PLEX-MICRO-8W | 8W | 24V DC | 4000K | 540lm/640lm/680lm/720lm | ≥90 | IP54 | Yes |
|
|
|
24164 | PLEX-MICRO-8W | 8W | 24V DC | 5000K | 540lm/640lm/680lm/720lm | ≥90 | IP54 | Yes |
|
Variant ID
24118
Item No.
PLEX-MICRO-8W
Wattage
8W
Input Voltage
24V DC
Colour Temperature
2700K
Lumens per metre
540lm/640lm/680lm/720lm
CRI
≥90
IP Rating
IP54
Dimming
Yes
Variant ID
24162
Item No.
PLEX-MICRO-8W
Wattage
8W
Input Voltage
24V DC
Colour Temperature
3000K
Lumens per metre
540lm/640lm/680lm/720lm
CRI
≥90
IP Rating
IP54
Dimming
Yes
Variant ID
24163
Item No.
PLEX-MICRO-8W
Wattage
8W
Input Voltage
24V DC
Colour Temperature
4000K
Lumens per metre
540lm/640lm/680lm/720lm
CRI
≥90
IP Rating
IP54
Dimming
Yes
Variant ID
24164
Item No.
PLEX-MICRO-8W
Wattage
8W
Input Voltage
24V DC
Colour Temperature
5000K
Lumens per metre
540lm/640lm/680lm/720lm
CRI
≥90
IP Rating
IP54
Dimming
Yes
